Kld2010 portable oil particle size counter



main features

◆ it is used for rapid particle analysis of field sampling at laboratory level. It is suitable for the determination of cleanliness of various kinds of oil, water-based solution (including water), chemicals and other liquids.



◆ 32 channels can be customized with high-precision measurement unit, good repeatability and high measurement accuracy



◆ built in new plunger metering pump system, flow regulation is not affected by viscosity and pressure, which can be used for sampling and measurement of pressureless bottle.



◆ equipped with optional pre flushing sensor function before each measurement to ensure measurement accuracy.



The sensor adopts Mie optical theory and mathematical model to ensure the measurement accuracy of particle number in each particle size range



◆ different measurement methods can be selected (single measurement and measurement method of specified measurement times)



◆ it can be applied to the measurement of high viscosity liquid (the flow of high viscosity liquid can be controlled by adjusting the drive motor)



◆ capacity to store 2 million measurement data. (optional hard disk) the measurement data can be extracted to the computer through software for analysis.



◆ it can be tested according to the new standards ISO4406 (1999), ISO4406 (1991), nas1638b; according to customer requirements, it can be installed into sae-749d standard, gjb420a-96 standard, toct17216-71 standard. Other standards can be customized.



◆ according to ISO4406, particle analysis can measure 1-24 grades; according to nas1638, it can measure 0-12 grades, and the measurement range is 1-400 μ M



◆ 5.7-inch color touch screen, built-in printer, with self calibration program. Equipped with 24V, 3A DC power supply, if you need to use in the field, you can choose charging battery power supply.



Specific performance parameters

◆ low pressure oil suction port: M14 measuring interface, maximum pressure 1MPa



◆ oil outlet: M14 measuring interface



◆ pressure pulsation: allowed



◆ medium: hydraulic oil, fuel oil, kerosene, water and other transparent liquids



◆ viscosity: pressure oil port max. 550 mm2 / S,



Low pressure oil suction port max. 320 mm2 / S



◆ ambient temperature range: 0-55. C. Medium: 0-80. C



◆ sensor flow: 30ml / min



◆ flushing flow: 30ml / min



◆ measurement volume: 10-250ml, adjustable



◆ flushing volume: 10-250ml, adjustable



◆ sensor: laser diode sensor



◆ number of channels: 32



◆ display according to nas1638: 5-15 / 15-25 / 25-50 / 50-100 / > 100 μ M



◆ NAS level measurement range: level 0-12



◆ display according to ISO4406 (1991): > 2 / > 5 / > 15 μ M



◆ display according to ISO4406 (1999): > 4 / > 6 / > 14 μ M



◆ ISO4406 measurement range: level 1-24



◆ calibration: acftd dust (iso4402)



ISO MTD dust (iso111171)
