Kyn3103 automatic kinematic viscosity tester

The machine is a fully automatic measuring instrument for measuring the kinematic viscosity of transparent or opaque fluid. It is controlled by MCS single chip microcomputer, and the process of constant temperature, testing, printing, cleaning and drying of viscosity tube is fully automatic. Its comprehensive technology is in the leading position in China, and the instrument conforms to gb265-88 standard. Widely used in petroleum, chemical industry, oil field, railway, scientific research, measurement and other departments. The instrument has the advantages of high accuracy, good repeatability and reproducibility, and simple and convenient operation.




Instrument function:

   1. It can measure the kinematic viscosity of two samples asynchronously at the same time.

   2. The measurement process includes: constant temperature, detection, calculation, viscosity tube cleaning, drying automatic.

   3. Allow users to set and change parameters by themselves. The instrument automatically calculates the test result and the actual error value. In case of out of tolerance, it will automatically retest until it meets the requirements.

                  .

   5. LCD display mode.

                       .

                 .

   8. Temperature control point: 0 ℃ ~ 100 ℃

                  .




Main technical indicators:

   1. Temperature control accuracy: ± ≤ 0.1 ℃

   2. Measurement accuracy: ± 0.05s

   3. Maximum timing time: 999.9 seconds




Specification of standard Ubbelohde viscosity test stand:

  Φ0．4、 Φ0．6、 Φ0．8、

  Φ1．0、 Φ1．2、 Φ1．5、

  Φ2．0、 Φ2．5、 Φ3．0、

  Φ3．5、 Φ4．0
