Abakus-y particle size detector

Product configuration description and supply details

1、 Main performance parameters:

Measurement range: 1-400 μ M

Pressure oil port: M16 measuring interface, maximum pressure 31.5Mpa

Low pressure oil suction port: 6L type ferrule joint, maximum pressure 1MPa

Oil return port: 6L type ferrule joint

Medium: hydraulic oil, fuel oil, turbine oil and other mineral oil

Viscosity: pressure oil port max. 500mm2 / S

Low pressure oil suction port max. 68mm2 / S

Temperature range: Environment: 0 ～ 50 ℃

Medium: 0-80 ℃

Sensor flow: 20ml / min

Flushing flow: 20ml / min

Measuring volume: 10-100ml, adjustable

Washing volume: 0-50ml, adjustable

Sensors: laser diode sensors

Number of channels: 32

Can be connected with computer, Chinese operation interface

Power supply: 220V, 50Hz

Measurement method: pressure system measurement or bottle sampling measurement in the laboratory

Built in printer with self calibration program

Results output: according to the international standards nas1638, ISO 4406 (1991), ISO 4406 (1999) and Russian standards (toct17216-71) and other pollution classification standards, the detection and analysis were carried out

2、 Supply details:

1. One "Abakus portable particle counter" produced by Klotz (Klaus) Company in Germany (origin in Germany);

2. One power plug connection;

3. One oil suction hose and one oil outlet hose;

4. One set of product manual (in Chinese and English);

5. One set of product installation software;
