Kbs7903 closed flash point automatic tester




Applicable standard: GB / 261-2008, ASTM D93

Instrument features:
◆ 320x240 large screen LCD display, touch screen operation, full Chinese display, rich display content, friendly human-computer interface;
◆ the unique system design with patent protection, the whole test process is fully automated, detection, cover opening, ignition, alarm, cooling, printing and other automatic completion;



◆ the unique design of the external heating furnace with patent protection realizes the complete separation of the high temperature furnace body and the circuit part of the instrument, greatly improves the service life of the instrument, and ensures the measurement accuracy of the instrument;



◆ unique switch power supply design with over-voltage, over-current, overheat automatic power-off protection to ensure the safe operation of the instrument;



◆ the built-in automatic detection chip of atmospheric pressure realizes the automatic measurement, automatic correction and automatic correction of flash point value of atmospheric pressure;



◆ adopt self-adaptive PID control algorithm to automatically adjust the temperature rise curve according to the standard requirements;



◆ automatically stop detection and alarm when the temperature exceeds the value; automatically analyze whether the test results meet the standard requirements, and provide relevant prompt operation,



◆ thermal micro printer, making printing more beautiful and faster, with offline printing function;



◆ automatically record and store the test results with time mark, and store up to 256 data;



◆ standard RS232 interface or Bluetooth communication function, which can transmit measurement data in real time, convenient and quick (optional);




Main technical parameters:



◆ range: 0 ～ 400 ℃



◆ repeatability: flash point range, ℃ allowable error



≤ 110℃ ±1℃



≥ 110℃ ±2℃



◆ resolution: 0.1 ℃



◆ temperature sensor: high precision platinum resistance (PT1000)



◆ flashover sensor: high precision thermocouple



◆ maximum power consumption: less than 300W



Heating rate: in accordance with GB / 261-2008



◆ cooling mode: forced air cooling



◆ printer: thermal, Chinese characters, 40 lines



◆ instrument weight: 8kg
