KSF6033 Decomposition Test Instrument --(color screen)

Ksf6033 SF6 decomposition analyzer



Dynamic temperature correction compensation technology: built-in sensor temperature characteristic curve, according to the sensor temperature characteristic curve, double dynamic correction of zero point and sensitivity is carried out to ensure reliable measurement results;

Self calibration design: this instrument is designed to open the calibration platform of zero point, sensitivity (range), cross interference. Users can use only a single concentration of standard gas to complete daily calibration.



technical parameter

◆ minimum detection amount: 0.1ppm

◆ stability: when the temperature changes 20 ℃ ~ 40 ℃, the maximum zero drift is ≤± 0.1ppm

◆ accuracy: when the measurement is ≤ 2ppm, the error is ≤± 0.1ppm

◆ when the measurement is > 2ppm, the error is ≤± 0.2ppm

◆ measurement range: SO2: 0-100 μ L / L

H2S：0～100μL/L

CO： 0～1000μL/L

◆ measurement tolerance: SO2 ≤ 10 μ L / L, ± 1 μ L / L; SO2 > 10 μ L / L, ± 10%,

H2S≤10μL/L,±1μL/L；H2S>10μL/L,±10％

CO≤50μL/L,±4μL/L；CO>50μL/L,±8％

◆ repeatability: SO2 ≤ 10 μ L / L, ± Zero point five μL/L；SO2>10μL/L,±5％，

H2S≤10μL/L,± Zero point five μL/L；H2S>10μL/L,±5％

CO≤50μL/L,±2μL/L；CO>50μL/L,±4％

◆ resolution: SO2 ≤ Zero point one μL/L，H2S≤ Zero point one μL/L，CO≤1μL/L

◆ response time: no more than 5min at most.

◆ pressure: the pressure of instrument pipeline shall not be less than 1MPa.

◆ temperature range: - 40 ℃ ~ + 50 ℃

◆ humidity range: ≤ 95% RH

◆ atmospheric pressure: 86kpa ~ 106kpa

◆ self provided power supply: built in rechargeable battery, which can work continuously for more than 10 hours after full charge

◆ appearance: 252 × 310 × 98mm

◆ weight: 2.5kG

◆ communication: RS232
