KSF8068 SF6 comprehensive tester
Source：Shandong Ketong Author：Shandong Ketong Date：2020-03-17 Visits：785
型号：KSF8068
品牌：
产地：
价格：
Ksf8068 SF6 comprehensive tester
Performance characteristics
◆ imported precision sensor, dew point (micro water), purity, decomposition products measurement automatic zero calibration, anti oil, anti drift.
◆ good repeatability, long-term stability, reliability, fast response, simple operation, easy to carry, intelligent power display.
◆ multiple temperature correction modes: a variety of temperature correction methods recommended in the power standard are integrated. Different temperature correction methods can be selected according to different equipment types, and the measurement results are more accurate.
◆ gas filtering function: the instrument has built-in filter, which can completely filter out the metal fluoride particles and improve the measurement accuracy.
◆ internal all stainless steel pipeline: effectively prevent the secondary pollution of instrument pipeline.
◆ wide measuring range, high precision and quick response.
◆ intelligent with complete functions.
◆ fast data storage and query function.
◆ the probe is not affected by condensation, special pollution, oil and gas and most chemical environments.
◆ AC / DC dual-purpose, built-in rechargeable lithium battery, can work for several hours continuously.
technical parameter
Purity
Measurement range: 0% ~ 100%
Measurement accuracy: ± 0.5%
Measurement time < 2 minutes
Dew point
Measurement range: - 80 ℃ ~ + 20 ℃
Measurement accuracy: ± 0.5 ℃ (- 80 ℃ ～ - 60 ℃)
Response time (+ 20 ℃): 5 seconds for 63%, 45 seconds for 90% (- 60 ℃ ~ + 20 ℃)
63% takes 10 seconds, 90% takes 240 seconds (+ 20 ℃ ~ - 60 ℃)
Testing H2S
Measurement range: 0 ~ 200ppm
Minimum detection amount: ≤ 0.1ppm
Accuracy: ± 0.5%
Stability: 0 ~ 200ppm
Repeatability: ≤ 2%
Testing SO2
Measurement range: 0 ~ 200ppm
Minimum detection amount: ≤ 0.1ppm
Accuracy: ± 0.5%
Stability: 0 ~ 200ppm
Repeatability: ≤ 2%
Testing CO
Measurement range: 0 ~ 1000ppm
Minimum detection amount: ≤ 1ppm
Accuracy: ± 0.5%
Stability: 0 ~ 100ppm
Repeatability: ≤ 2%
◆ ambient temperature: - 40 ℃ - + 60 ℃
◆ environmental humidity: 0-100% RH
◆ power supply: AC 220V or built-in rechargeable battery
◆ battery performance: charging time: 20 hours; service time more than 10 hours
◆ weight: 5 kg
◆ size: 250 × 150 × 300mm3
◆ working temperature: - 40 ℃ - + 80 ℃
