KHR-3 ash melting point

Khr-3 ash melting point




The rapid ash analyzer is a new type of special equipment for ash content determination of coal or other combustible materials. Put the tested sample on the conveyor chain, enter the high temperature zone for combustion along with the chain, and then send it out of the furnace. Because the sample enters the high temperature zone slowly, the deflagration of the sample is avoided. In addition, the conveying chain speed is stepless and adjustable, and the ashing time can be changed according to the requirements of the sample.



Scope of application:



It is suitable for coal, electric power, metallurgy, scientific research and other industries and departments to determine the ash content of coal, coke and other combustible materials.



Kkh-3 rapid ash analyzer is a new type of coal analysis instrument, which is mainly used for ash in coal and coke. It can be used in laboratories of coal, electric power, metallurgy and geological exploration departments.



Based on the national standard gb212 "industrial analysis method of coal", the instrument is designed and produced with high and new technology, which has the characteristics of accuracy, high efficiency and energy saving.



1. The furnace adopts inclined assembly and natural air circulation, so that the sample can get enough combustion supporting air, which greatly shortens the ashing time compared with the traditional high temperature furnace ashing method.



2. The ideal temperature gradient can be formed in a long furnace, and the sample gradually enters the high temperature zone from low temperature, which is similar to the slow ash process, which solves the problem of deflagration that is not easy to be solved by the high temperature ash method, and improves the measurement accuracy.



3. With chain transmission, the sample in and out is continuous and automatic, and the speed is adjustable. Its measuring effect is 4-5 times of that of high temperature furnace.



4. According to different samples, the user can adjust the running speed and the burning time, so that the samples can be fully burned.



5. Energy saving: energy consumption is one third of that of ordinary high-temperature furnace.



Functional features:



1. Adopt single chip microcomputer technology to measure and control, correct temperature and current in real time, with high degree of automation.



2. High brightness LED digital display, intuitive, accurate, stable and reliable performance.



3. Adopt chain transmission, continuous automatic transmission, stable operation, and adjustable speed.



4. Compared with muffle furnace, the instrument has a better method, which has been included in the national standard; it has high accuracy and small error; it has a fast measuring speed and an efficiency of 4-5 times that of muffle furnace; it can save one third of energy than muffle furnace.



Technical parameters:



Temperature control range: 100-1000 ℃



Temperature measurement accuracy: class 0.2 temperature control accuracy: ± 10 ℃



Furnace length: 700mm, constant temperature zone length: ≥ 200mm



Transmission speed: (15-70) mm / min



Length of constant temperature belt: ≮ 150 mm at 815 ℃, temperature difference ＞ ± 10 ℃



Heating time: (from room temperature to 815 ℃) 45min



Chain running speed: 15-70mm / min (ashing time: 15-50min)



Measurement accuracy: better than gb212 standard



Power: 3kw



Working power supply: 220V ± 22V, 50Hz ± 1Hz



Boundary dimension (mm): 1200 × 420 × 505



Weight: 70kg
